Spectra QX40 Pixel MKII

Equipped with 40 x 15W RGBW LEDs, the QX40 is suitable for illuminating event spaces, stages or facades, while the zone control allows lighting designers to create stunning effects. The unit utilises quad-colour LED technology to produce a wide colour spectrum from rich, primary colours through to subtle pastel hues. Designed for rental and events, the QX40 features quick release omega brackets, PowerTwist TR1 connectors for power input/output and also features both wired and wireless DMX by W-DMX Sweden. The slim profile of the fixture is ideally suited for loading into road trunks holding multiple units. A range of optional accessories including beam shaping lenses, snoots and barndoors further widen its applications.


Please Enquire for Prices
Category:

Technical Specification

  • Features
  • 40 x 15W quad-colour LEDs (RGBW)
  • Beam angle: 8°
  • 8° – 67,847 Lux @ 2m (full on)
  • Refresh rate: 3kHz
  • Pixel zone mapping
  • Wireless DMX control by W-DMX Sweden
  • DMX channels: 1/3/4/6/9/20 or 25 selectable
  • RDM (Remote Device Management)
  • Static colour, colour change and colour fade modes
  • Master/slave mode when cabled
  • 0 – 100% dimming
  • 4 dimming curves: Linear, square law, inverse square law and S-curve
  • Variable strobe
  • Supplied with installation bracket and quick release omega clamps
  • 4 button menu with OLED display
  • PowerTwist TR1 input/output
  • IP rated 5-Pin XLR input/output
  • Fan cooled
